WSGMD2 COMPUTERIZED FLAT KNITTING

Securities code: 874017

Specifications and main functions
Gauge	3G/5G/7G/12G/14G/16G
Knitting Width	48"/52"/56"
Knitting System	Single carriage with double system
Knitting Function	Front single side, back single side, three flat, four flat, rib, turning needle, picking needle, hanging eye, jacquard, inlay, open close needle, dark close needle and other regular pattern knitting
Transfer	front or back, simultaneous transfer, independent of carriage direction
Needle Selection	Special design, 4 selection total
Control System	Screen display: LED touch screen,USB input,memory up to 2G,according to the production of call Monitoring menu: display current knitting parameters,can be adjusted at any time when the machine is operating Design and control system (software):Adopting the mainstream domestic flat knitting machine control system, easy to upgrade and free of charge configuration Multi language version: to increase the language according to customer's requirement.
Protection System	Machine will automatically alarm and display its item if any error as yarn-breaking,fail of racking needle,voltage instability,floating yarn and so on.
Power Supply	Single phase 220v,power 1kw,CMOS technology,with memory function at power-off moment,to continue knitting after restoring.
User Option	Takedown comb, no waste yarn comb
Customized service	Customizable according to customer's requirement
